Customized Epoxy Powder Coating Powder High Gloss Semi Gloss And Non Gloss Options

Customized Epoxy Powder Coating Powder High Gloss Semi Gloss And Non Gloss Options

Brand Name:	CHG
Model Number:	PCP-01
MOQ:	20 kg
Price:	Negotiable
Payment Terms:	L/C, D/P, T/T, Western Union, MoneyGram
Supply Ability:	20000 ton per year

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE, ISO

Specific Gravity:

1.4-1.8g/cm3 (Depends On The Formula And Colors)

Distribution Of Granularity:

Average 30-50μm, 99%<100μm, 60-70%>32μm

Application Area:

High Voltage Static Powder Spray Coating

Condition:

New

After-sales Service:

Guide Equipment Installation And Use

Customization:

Available

Packaging Details:

60.00cm * 40.00cm * 25.00cm

Highlight:

Customized Powder Coating Powder

Epoxy Powder Coating Powder

Custom Epoxy Powder Coating

Product Description

Customized Epoxy Powder Coating Powder With High Gloss Semi Gloss And Non Gloss Options For Different Industry Requirements

Epoxy Powder Coating
Characteristic
specific gravity: 1.4-1.8g/cm3, depends on the formula and colors.
Distribution of granularity: average 30-50μm, 99%<100μm, 60-70%>32μm
Application
application area: high voltage static powder spray coating, friction static coating
Layer thickness: 50-150μm depends on different industry requirements
Coverage: 9-12m2/kg (layer thickness 60μm)
Packaging and store
20kg cartoon with plastic bag inside.
Away from heat sources, avoid direct sunlight, below 30ºC and dry environment. Shelf life is 24 months.
Curing
Low Temperature Curing: 160ºC, 20Mmin (workpiece temperature)
Normal Temperature Curing: 180ºC, 20Mmin (workpiece temperature)
Fast Curing: 200ºC, 10Mmin (workpiece temperature)

Exterior appearance
Luster: (GB/T9754-88, measure from 60 degree)
High gloss type >81%
Semi gloss type: 31-80%
Non gloss type: 3-30% customized
Appearance: flat smooth, little crinkle
Mechanical Characteristic
Pencil Rigidity: GB/T6739-1996 > 2H
Blow test: GB/T1732-1993 50Kg.cm
Cupping test: GB/9753-1988 > 6mm (depends on formula and colors)
Bending test: GB/T6742-1986:2 mm
Adhesive force: GB/T9286-1998:0 grade
Anti-Corrosion
Salt Spray Test: GB/T10125-1999: no impact on coated layer after 1000 hours and the corrosion of section is less than 2mm.

	Type of Powder
Property	Standard Polyester	Enhanced Polyester	Epoxy	Hybrid	Polyurethane	Acrylic	PVDF
Exterior Durability	Good	Excellent	Very Poor	Poor	Good	Excellent	Excellent
Corrosion Resistance	Good	Good	Excellent	Good	Good	Good	Good
Impact	Excellent	Poor	Excellent	Excellent	Good	Poor	Excellent
Flexibility	Excellent	Good	Excellent	Excellent	Good	Good	Excellent
Adhesion	Excellent	Excellent	Excellent	Excellent	Excellent	Excellent	Poor
Cost	Medium	Medium / High	Medium	Low	Medium	High	High
Film Appearance @ 50µ	Good	Very Good	Good	Good	Excellent	Good	Poor
Volatile Emissions	Very Low	Very Low	Very Low	Very Low	Low	Very Low	Very Low
Low Bake	Yes	No	Yes	Yes	No	Yes	No
Chemical Resistance	Good	Good	Excellent	Very Good	Good	Very Good	Good
Gloss Range	10-95%	20-95%	5-90%	5-90%	5-95%	30-90%	30-60%
Heat Resistance	Very Good	Good	Poor	Good	Very Good	Good	Good
Abrasion	Good	Good	Very Good	Good	Good	Good	Poor
Compatibility	Good	Good	Good	Good	Good	Very Poor	Very Poor
