products details

Created with Pixso. Home Created with Pixso. Products Created with Pixso.
Spray Guns
Created with Pixso.

Automatic Electrostatic Powder Spray Gun for Coating Machine Spray Booth with Control Unit

Name

Automatic Electrostatic Powder Spray Gun for Coating Machine Spray Booth with Control Unit

Brand Name: CHG
Model Number: CB-PC-04
MOQ: 1 set
Price: Negotiable
Payment Terms: L/C, D/P, T/T, Western Union, MoneyGram
Supply Ability: 1000 sets per year
Detail Information
Product Description
Detail Information
Place of Origin:
China
Certification:
CE, ISO
Model NO.:
CB-PC-04
Voltage Output Of Static Generator:
DC240V
Specification:
Customized
Origin:
China
Package Gross Weight:
0.800kg
Shipping Cost:
Contact The Supplier About Freight And Estimated Delivery Time.
Packaging Details:
Varies depending on the design
Product Description

Automatic Electrostatic Powder Coating Spray Gun



Key Features:

1. Complete System Configuration

  • Automatic electrostatic spray gun

  • High-voltage controller unit

  • Powder suction pump

  • Electrically insulated transfer piping

2. High-Efficiency Electrostatic Application

  • Built-in high-voltage generator (60-100kV)

  • Optimized electrostatic field distribution

  • Leakage-proof electrical system

3. Advanced Spray Technology

  • Triple-airflow technology ensures:
    • Uniform powder distribution (±5%)
    • Continuous nozzle cleaning
    • Consistent spray fan pattern

4. Reliable Powder Delivery System

  • Fluidized bed powder hopper prevents:
    • Material bridging
    • Flow interruptions

  • Dual-airflow pump provides:
    • Stable powder transport (1-5kg/min)
    • Even feed to spray gun

Technical Specifications:

  • Voltage range: 60-100kV

  • Powder output: 1-5kg/min

  • Air consumption: 3-6 CFM

  • Coating uniformity: ±5%

No. Item Parameter
1 Voltage input ~220V 50~60 Hz
2 Voltage output of static generator DC24V
3 Voltage output of powder spraying gun 0-100kV continuously tunable
4 Current output ≤100μA
5 Polarity negative
6 Spraying gun weight 500g
7 Powder output 0-400g tunable
8 Compressed air consumption Max0.25Nm3/min
9 Powder bucket volume 25kg
10 Pipeline length By actual demand
11 Protection degree IP54





Automatic Electrostatic Powder Spray Gun for Coating Machine Spray Booth with Control Unit 0
